Part No: 833.75.933
LED Driver 24 V, without Mains Lead, Rated IP 20, Loox5 Eco
£21.28
(excl. VAT)
LED Driver 24 V, without Mains Lead, Rated IP 20, Loox5 Eco
Part Number: 833.75.935
With switching function for 1 switch, Length x width x height 188 x 57 x 16 mm, Wattage 0 - 40 W
Price:
£35.65
Per Item
LED Driver 24 V, without Mains Lead, Rated IP 20, Loox5 Eco (Part No: 833.75.935) is a compact, efficient LED... Read More
Product Information
Product Details
LED Driver 24 V, without Mains Lead, Rated IP 20, Loox5 Eco (Part No: 833.75.935) is a compact, efficient LED driver designed to power 24 V lighting systems with confidence. Built for modern installations, this Loox5 eco driver features a practical switching function for seamless control from a single switch connection—ideal for clean, clutter-free setups.
With a mains voltage of 220–240 V (50–60 Hz), the driver converts power to a stable 24 V DC output for LED lighting only. It’s rated for an adjustable 0–40 W load, with a reliable efficiency of 86% at 230 V full load. Even when idle, it has a low 0.50 W no-load power consumption, helping keep running costs under control.
The Loox5 Eco Driver w Sckt is engineered for real-world conditions, operating in -25–45 °C ambient temperatures. Safety and longevity are also covered thanks to overload protection and the Hafele Lifetime Guarantee of 7 years.
Measuring 188 x 57 x 16 mm, it offers flexible installation options including glue fixing and screw fixing. It connects via 4 x sockets (Loox5 2-pin 24 V) and includes an input for 1 x socket (Loox switch). Please note: Loox mains leads must be ordered separately (e.g. 833.89.000).
Choose the Loox5 Eco Driver for a streamlined, dependable 24 V LED solution—right for professional results and easy upgrades.
Specifications
Mains voltage
220 – 240 V
Mains frequency
50 – 60 Hz
With switching function
Yes
Ambient temperature
-25–45 °C
Number of switch connections
1.00
Version
With overload protection
Suitable for
220–240 V AC: typical mains voltage e.g. for EU, UK, AU, KR – not US!
Output voltage
24 V DC
Area of application
LED (no other device)
Area of application
For LED lights (not suitable for other devices)
Suitable for
24 V consumer with Loox plug system
Material
Plastic
Colour/finish
Black
Connected output ports
4 x sockets, Loox5 2-pin 24 V
Control input ports
1 x socket, Loox switch
Installation
for glue fixing, Screw fixing
Efficiency at 230 V full load
86 %
Power consumption at 230 V no load
0.50 W
Hafele Lifetime Guarantee
7 years
Output current
1.67 A
Order reference
Loox mains leads must be ordered separately; e.g. 833.89.000
Supplied with
Fixings
FAQ
Product Details
Can I use this LED driver with non Loox LED lights?
This unit is designed for LED applications only. It is intended to work with 24 V consumer products that use the Loox plug system. For best results, check that your LED fittings and connectors are compatible with Loox 24 V connections.
Does the driver include a mains lead, or do I need to order one separately?
You will need to order the Loox mains lead separately. The product includes the fixings, but the mains connecting cable is not supplied. A common example is 833.89.000.
What does the switching function do?
The driver supports a single switch connection (one control input). This means you can turn your 24 V LED load on or off using a compatible Loox switch, while the driver handles the controlled 24 V output.
What output and maximum wattage can it supply?
Output is 24 V DC and the driver is suitable for LED loads up to 40 W. Make sure the total wattage of the connected LEDs stays within this limit for reliable operation.
Is it suitable for installation in warm or cold environments?
Yes, it is rated for an ambient temperature range of minus 25 to 45 degrees Celsius. That makes it suitable for many common indoor and workshop style locations, provided it is installed correctly and kept free from excessive heat and moisture.
How is it installed and can I mount it using adhesive?
It supports glue fixing and screw fixing. If you are working on a Loox system installation, choose the method that fits your setup and ensure the driver is securely mounted for stable long term use.
What safety features are included?
This driver includes overload protection. That helps safeguard the driver when the connected load is outside normal operating conditions, supporting safer day to day use.
