Drilling Jig, for 89 mm and 128 mm Height, Matrix Box Slim A

Product Details

What is the MX Slim A Front Drilling Jig 175mm used for?

The MX Slim A Front Drilling Jig 175mm is designed for easy marking of the fixing holes for the front panel for Matrix Box A. It helps you position holes accurately before drilling, which can save time and reduce the chance of misalignment.

Which drawers does this drilling jig suit?

This jig is suitable for Matrix Box Slim A 175 mm high drawers. Using the correct jig for the specific drawer height helps ensure the fixing holes match the hardware and front panel requirements.

Will it work with my panel thickness?

Yes. This jig is intended for 16 mm panel thickness. If your front panel is a different thickness, the hole positions may not line up correctly, so it is worth checking before starting.

Does it come with wall plugs and what sizes are they?

Yes. The version supplied includes wall plugs for 89 mm and 128 mm configurations. If your installation requires one of these distances, having the appropriate wall plug included makes setup more straightforward.

Is the jig compatible with slim drawer installations where alignment is critical?

Designed specifically for the Matrix Box Slim A 175 mm high drawer system, the jig supports consistent hole positioning for the front panel. Using a drilling jig is a practical way to keep alignment accurate, especially when fitting multiple fronts.

What will I receive in the box?

The jig is supplied with mounting instructions. Follow the instructions to set up the jig properly on the panel and achieve accurate marking before drilling.

Why choose a steel drilling jig for front panel hole marking?

This drilling jig is made from steel, which provides a solid, stable tool for marking and drilling tasks. A rigid jig helps maintain accuracy during use, making it a reliable choice for home or trade installations.
