Floor Spring, Mechanism and Box, Power Size 3-6, TS 550 NV FP, Geze

Product Details

Floor Spring, Mechanism and Box, Power Size 3-6, TS 550 NV FP, Geze is a reliable, high-performance floor spring mechanism designed for Moveable Wall Systems, sliding and folding doors. Built for smooth, controlled door operation, this unit is ideal when you want dependable closing action without an integrated hold-open feature.

With the product subtitle Without hold open, the TS 550 NVFP floor spring mechanism is made to suit commercial door applications where consistent self-closing performance is essential. It supports door panels up to a maximum width of 1,400 mm and handles door weights of ≤300 kg, making it a strong choice for larger moving wall configurations.

Engineered to comply with EN 1154, the closing force is set to 3–6, helping deliver stable operation day after day. The mounting is suitable for both DIN left and DIN right installations, ensuring easier planning and installation across different site layouts.

Ordering convenience: Please note that the mechanism requires specific additional components. You may need to order the order cover plate separately (Cat. No. 932.10.130), and pivot fittings separately, depending on your door system setup.

For installation readiness, the TS 550 NVFP is supplied with a cement box with adjustable position (6 mm vertical, 10 mm lateral and 10 mm length) plus fixings—so you can achieve a proper fit with confidence.

Choose Floor Spring, Mechanism and Box, Power Size 3-6, TS 550 NV FP, Geze (Part No: 932.10.180) for smooth, controlled door closing in your sliding or folding moveable wall system.

Order cover plate, Cat. No. 932.10.130 separately
Order pivot fittings separately

Cement box - adjustable position (6 mm vertical, 10 mm lateral and 10 mm length)
Fixings
