Mortice Clawbolt WC Lock 5/57/76mm SSS
Part Number: 911.26.159
5 mm follower, backset 57 mm, case size 76 mm, satin stainless steel
Price:
£38.48
Per Item
Clawbolt operated by turn/emergency release or flush ring handle, single actionCase: Epoxy powder coated, 14 mm... Read More
Product Information
Product Details
Clawbolt operated by turn/emergency release or flush ring handle, single action
Case: Epoxy powder coated, 14 mm wide
Forend: Square, 2 piece
Strike plate: Square, flat
Clawbolt: 14 mm throw
Follower: 5 or 8 mm
| Technical data | ||
|---|---|---|
| Type of locking | WC/Bathroom | WC/Bathroom |
| Deadbolt throw | 1 turn | 1 turn |
| Deadbolt throw dim. | 14 mm | 14 mm |
| Lever follower | 5 mm | 8 mm |
Specifications
Type of locking
WC/Bathroom
Forend Type
57.00 mm
Forend design
Flat forend edged
Forend width
25.00 mm
Mounting
DIN left/right
Material
Case: Steel
Forend and strike plate: Stainless steel or brass
Clawbolt and follower: Brass
Latchbolt version
Without latch
For door type
Bathroom/WC doors, Sliding doors
Colour/finish
Satin stainless steel
Forend length
134.00 mm
Deadbolt version
Claw deadbolt
Supplied with
Strike plate
Fixings
