Accuride 1234 Pivot Sld Dr Run Blk 354mm
Rated 3.5/5 based on 11 customer reviews
Hafele

Accuride 1234 Pivot Sld Dr Run Blk 354mm

  • Product SKU: 408.35.336
  • Availability: In Stock
£43.04

Price inc. VAT

£43.04
Hurry! only 25 left in stock!
Ask about this product
Your message has been successfully sent to the store owner!
Hold-out feature at maximum extension for ease of door operationDoor supports required when fitting horizontallyInstalled in 3 easy stepsHinge carrrier strip, 15 mm thickness, to be supplied by customerTested to 80,000 cycles
  • Application: Inset or half overlay cabinet doors
  • Installation: Screw fixing
  • Door weight: Max. 14 kg
  • Door height: Max. 1100 mm
  • Door width: Max. 610 mm
  • Door thickness: 16-32 mm
  • Material: Steel
  • Finish: Black zinc plated
  • Order reference: Hinges and mounting plates to be ordered separatelyFor inset applications, hinge 348.31.802 and mounting plate 348.38.512For half overlay applications, hinge 322.13.630 and mounting plate 322.85.750
