Dialock WTX202 Relay Unit
Part Number: 917.91.085
For extending the WT 210 wall terminal by 2 relays and 2 input ports
Price:
£133.86
Per Item
Functionality The WTX 202 add-on unit is intended for connecting to the WT 210 wall terminal. It takes over the... Read More
Product Information
Product Details
Functionality
The WTX 202 add-on unit is intended for connecting to the WT 210 wall terminal. It takes over the control of the inputs and outputs of the WT 210 and is fitted to a top-hat rail in a control cabinet in the secure indoor area. This ensures that increased safety requirements are also met. The WTX 202 is compatible with the WT 210 and the WT 210 BLE with a firmware version of 9.x.0.33 or above.
Order reference
For help, advice and ordering of our full range of Dialock access control systems please get in touch with our Project team, 0800 171 2907 or
Specifications
Product category
Relay Unit
Area of application
For extending the WT 210 wall terminal by 2 additional relays and 2 input ports
Version
Communication between the WTX 202 relay unit and the WT 210 wall terminal is encrypted with AES-128
Housing material
Plastic
Housing colour/finish
Light grey
Installation
For clipping onto hat rail
