Duomatic 3mm Mounting Plate SM Cruci Euro

Part Number: 329.71.513
For side panel thickness 19 mm, Height 3 mm, hole centres: 32 mm
Price:
£1.75
Per Item
VAT excluded
Product Information

Specifications

Area of application

For click on systems

Version

With quick fixing systems and eccentric adjustment

Material

Zinc alloy

Colour/finish

nickel plated

For drill hole Ø

5.00 mm

For side panel thickness

19 mm

Drilling depth

11.00 mm

Screw distance

32.00 mm

Edge distance

37.00 mm

Adjustment facility

Height adjustment Via eccentric ±2 mm, Depth adjustment Via eccentric -0.5 mm to +2.8 mm

Fixing method

Quick fixing system SM

Mounting plate version

For screw fixing with pre-mounted Euro screws

Distance

3.00 mm

Manufacturer

Häfele

Model series

Häfele Duomatic SM Cruciform mounting plate

Suitable for

Häfele Metalla 510 concealed hinges
