NO. 51 2" (2 LEVER) BRASS STRAIGHT CUPBOARD LOCK

No.51 (2 lever) Straight cupboard locks are double handed and can fit on either edge of the door.

Available in following sizes -
2" (2 lever)
2" x 1 1/8" x 7/16" (51 mm x 28 mm x 11 mm)
Distance To Pin: 9/16" (14 mm)

Material: 2 Brass Levers, Brass Cup, Screwed Brass Plate, Brass Bolt.
Finish: Sanded Cup & Plate, Self Colour Bolt.
Keys: 2 Keys Per Lock, Malleable Iron, Nickel Plated.
Differs: 12 Differs OR Keyed Alike.

Please specify when ordering size and whether keyed alike or keyed to differ.

No. 51 BRASS STRAIGHT CUPBOARD LOCK Straight cupboard locks fit directly onto the wood on the inside of the cupboard without the need for cutting any wood away. 2 or 4 LEVERS 12 DIFFERS DOUBLE HANDED DIMENSIONS: 1 5/8” x 15/16” ( 41 mm x 23 mm ) Distance To Pin: 7/16” ( 11 mm ) 2” x 1 1/8” ( 51 mm x 28 mm ) Distance To Pin: 9/16” ( 14 mm ) 2½” x 1 7/16” ( 63 mm x 36 mm ) Distance To Pin: 11/16” ( 17 mm ) 3” x 1 9/16” ( 76 mm x 40 mm ) Distance T

MATERIAL: Brass Cup, Screwed Brass Plate, Brass Bolt. FINISH: Sanded Cup & Plate, Self Colour Bolt. KEYS: 2 Keys Per Lock, Malleable Iron, Nickel Plated. SPECIAL OPTIONS: 1 Key Per Lock. To Pass / Keyed Alike ( No Extra Charge ). All To Differ. En-suite To Master Key. 2 Way Keyhole ( Not 1½” ). Suited With No.41’s, 48’s, 61’s & 15’s
