Kinvaro T-105 Flap Fit RH 1000x283mm

Part Number: 373.77.330

For top box units, Right hand

Price:

£12.17

Per Item

VAT excluded

Allows additional cabinet installation aboveSpring-assisted action for easy opening Order reference Concealed... Read More

Product Information

Product Details

Allows additional cabinet installation above
Spring-assisted action for easy opening

Order reference

Concealed sprung hinges with 95 to 105° opening angle must be ordered separately
Order Hospa Ø 3.0 and 4.0 mm countersunk screws separately

When using a bar handle please trial mount first
Did you know, you can use our Panel Weight Calculator to work out the weight of your panels?

Specifications

Area of application

For top box units
For chipboard or MDF flaps only

Material

Fittings: Zinc alloy
Cover caps: Plastic

Cover colour

Cover caps: Black

For cabinet width

450 – 1,000 mm

For cabinet height

283 – 450 mm

For lid weight

1.1 – 8.6 kg

Installation

For flap width 450-1000 mm

For lid height
