Startec Mort Cyl Escapelock 60/92mm SSS

Assessed for use on 30 minute (FD 30) and 60 minute (FD60) timber fire doors to BS EN 1634-1Latchbolt and deadbolt operated by lever handle inside and deadbolt by cylinderCase: Galvanized, 16 mm wideForend: Radius, 2 pieceStrike plate: Radius, Box included.Latchbolt: Bright zinc plated. Easily reversible. Anti-thrust deadlocksDeadbolt: Bright zinc plated. 20 mm throwFollower: Through 8 mm. Hold-tite spindle spring. For use with sprung furnitureHoled for bolt through furniture at 38 mm centres, top and bottomOnly requires a lever depression of approx. 25° to fully retract latchbolt

• Backset: 60.0 mm
• Case size: 92 mm
• Finish: Satin stainless steel
• Bolt throw: Deadbolt: 20 mm
• Material: Case: SteelForend and strike plate: Stainless steel or brassLatchbolt and deadbolt: Solid brassFollower: Brass
• Guarantee: 10 years
• Note: Where a fire rating is shown for a product this would only have been achieved by use of intumescent seals. When fitting any ironmongery to a door please ensure the correct intumescent product is used
• Supplied with: Strike plateFixings
• Order reference: Order cylinders and half spindle separately
• Warranty information: This product is covered under H‚Äö√†√∂¬¨√üfele‚Äö√Ñ√∂‚àö√ë‚àö¬•s Lifetime Guarantee.All products covered under the H‚Äö√†√∂¬¨√üfele Lifetime Guarantee have met our quality standards and have been tested according to the relevant industry certification.All products under this guarantee are covered for normal use of the products in a domestic environment - for commercial environments our standard 12 month guarantee would apply.
