Libra H1 Cabinet Hanger Conc UH SZP
![1/2 Carousel H500/D440mm Pl CrWht]()
![1/2 Carousel H500/D440mm Pl CrWht]()
![1/2 Carousel Set Wire 645-790 Cab 800mm]()
![1/2 Carousel Set Wire 645-790 Cab 800mm]()
Libra H1 Cabinet Hanger Conc UH SZP
- Product SKU: 290.41.900
- Availability: In Stock
£1.93
Price inc. VAT
£1.93Features an innovative anti-turnover device. Cabinet hanger concealed behind rear panel, only cover caps visible inside the cabinet. Vertical and horizontal adjustment. The two movements are 100% independent of each other and therefore make the adjustments much easier and more efficient
- Finish: Zinc plated
- Handing: Unhanded
- Application: For hanging wall units
- Installation: Screw fixing: A 3.5 x 20 mm lateral wood screw permanently secures the cabinet hanger in place (not provided)
- Load bearing capacity: 150 kg per pair (Load carrying capacity applies to 2 cabinet hangers bearing an evenly distributed load in accordance with regulation DIN 68840)
- Adjustment facility: Two-way independent adjustment: Vertical adjustment: 13 mm. Horizontal adjustment: 12 mm
- Material: Steel
- Note: Cabinet hangers should only be adjusted with a hand tool and not a power tool
- Order reference: Wall plates and cover caps must be ordered separately. Please note: The locking adjustment screw cannot be accessed if round cover caps are fitted, order rectangular cover cap if access to all 3 adjusting screws is required
