Accuride 1234 Pivot Sld Dr Run Blk 456mm
Part Number: 408.35.346
For horizontal or vertical use, Installed length 456 mm
Price:
£52.83
Per Item
Order reference Hinges and mounting plates to be ordered separatelyFor inset applications, hinge 348.31.802 and... Read More
Product Information
Product Details
Order reference
Hinges and mounting plates to be ordered separately
For inset applications, hinge 348.31.802 and mounting plate 348.38.512
For overlay applications, hinge 322.13.630 and mounting plate 322.85.750
Specifications
Area of application
Inset or half overlay cabinet doors
Material
Steel
Colour/finish
Black zinc plated
For door weight
≤14 kg
For door width
≤610 mm
For door height
≤1,100 mm
For door thickness
16 – 32 mm
Installation
Screw fixing
